All parts of the machine is made of AISI 304 Cr-Ni Stainless Steel.
Operates with NG (Naturel Gas) or LPG (Liquid Petrolum Gas).
MELTEM ® burners are used.
Safety System gas valves cut off the gas automatically when the burners go out.
Motor can be rotated at 1 r.p.m. to the right or left.
Motor is air-cooled and protected by heat shield.
Protective wires are made of AISI 310 Cr-Ni (heat-resisting) quality stainless steel, and they are durable.
Easy to perform general maintenance, repair and cleaning.
The walking body ensures ease of operation.
The ‘V’ type design enables fast cooking.
| Technical Specifications | ||||||
| MODEL | MV-4S | MV-5S | MV-5 | MV-6 | MV-7 | |
| A-Width | cm | 90 | 90 | 90 | 90 | 90 |
| B-Depth | cm | 117 | 117 | 117 | 117 | 117 |
| C-Height | cm | 102 | 119 | 119 | 202 | 218 |
| D-Max. Height of meat | cm | 70 | 85 | 85 | 100 | 115 |
| Cooking Capacity | Kg | 150 | 200 | 200 | 250 | 300 |
| Gas Inlet | Inch | 2x1/2" | 2x1/2" | 2x1/2" | 2x3/4" | 2x3/4" |
| Electric Lolet | V | 230 V AC 50 Hz (115 V AC 60 Hz) | ||||
| Type of Burner | MELTEM R-4 | |||||
| Burner | Pcs | 8 | 10 | 10 | 12 | 14 |
| Net Weight | Kg | 90 | 110 | 140 | 160 | 180 |
| Power | Kw | 28 | 35 | 35 | 42 | 49 |
